| 0082226102 | ||
|---|---|---|
|
|
||
|
||
| Product description : CBL RIBN 2COND 0.100 GRAY 100' | ||
| SPQ：9 | ||
| Datasheet : -- |
- Specifications
- Product Attributes
- Documents
- Product reviews
| Conductor Strand | 7 Strands / 36 AWG |
|---|---|
| Cable Type | Flat Cable |
| Voltage | 300V |
| Shielding | Unshielded |
| Number of Conductors | 2 |
| Features | Zippable |
| Ribbon Thickness | 0.051" (1.30mm) |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) |
| Series | 7560 |
| Conductor Material | Copper, Tinned |
| Operating Temperature | -20°C ~ 105°C |
| Ribbon Width | 0.200" (5.08mm) |
| Jacket Color | Gray |
| Wire Gauge | 22 AWG |
| Ratings | UL Style 2651 |
| Standard Package | 9 |
| First Conductor Mark | Red |
| Insulation Resistance | 10 MOhms |
| Length | 100' (30.5m) |
| Family | Flat Ribbon Cables |
| RoHS Information | 82226102 Cert of Compliance |
| Pitch | 0.100" (2.54mm) |
