| TLE4205 | ||
|---|---|---|
|
|
||
|
||
| 产品描述：
IC MOTOR DRIVER PAR 18DIP
|
||
| 标准包装：800 | ||
| 数据手册： -- |
- 规格参数
- 产品特性
- 技术文档
- 产品评论
| Voltage - Supply | 6 V ~ 32 V |
|---|---|
| Package / Case | 18-DIP (0.300", 7.62mm) |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Current - Output | 1A |
| Interface | Parallel |
| Family | PMIC - Motor Drivers, Controllers |
| Mounting Type | Through Hole |
| Technology | Bipolar |
| Output Configuration | Half Bridge (2) |
| PCN Obsolescence/ EOL | TLE4205 28/Nov/2011 |
| Supplier Device Package | P-DIP-18 |
| Standard Package | 800 |
| Voltage - Load | 6 V ~ 32 V |
| Applications | Automotive |
| Operating Temperature | -40掳C ~ 150掳C (TJ) |
| Motor Type - AC, DC | Brushed DC |
