| L06038R2DFWTR | ||
|---|---|---|
|
|
||
|
||
| 产品描述：
FIXED IND 8.2NH 300MA 350 MOHM
|
||
| 标准包装：3000 | ||
| 数据手册： -- |
- 规格参数
- 产品特性
- 技术文档
- 产品评论
| Tolerance | ±0.5nH |
|---|---|
| Package / Case | 0603 (1608 Metric) |
| Supplier Device Package | 0603 (1608 Metric) |
| Standard Package | 3,000 |
| Size / Dimension | 0.063" L x 0.032" W (1.60mm x 0.81mm) |
| Height - Seated (Max) | 0.028" (0.71mm) |
| Series | Accu-L® |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 125°C |
| Current Rating | 300mA |
| Inductance | 8.2nH |
| Type | Thin Film |
| Frequency - Self Resonant | 3.8GHz |
| Q @ Freq | 23 @ 450MHz |
| Packaging | Tape & Reel (TR) |
| Material - Core | Non-Magnetic |
| Family | Fixed Inductors |
| Shielding | Unshielded |
| DC Resistance (DCR) | 350 mOhm Max |
| Frequency - Test | 450MHz |
