| A22RS-2M-11 | ||
|---|---|---|
|
|
||
|
||
| Product description : SWITCH SELECT 2POS DPST 10A 120V | ||
| SPQ：1 | ||
| Datasheet : -- |
- Specifications
- Product Attributes
- Documents
- Product reviews
| Depth Behind Flange | 46.80mm |
|---|---|
| Switch Function | On-Off, Off-On |
| Ingress Protection | IP65 - Dust Tight, Water Resistant |
| Termination Style | Screw Terminal |
| Features | Bezel - Round |
| Electrical Life | 500,000 Cycles |
| Category | Switches |
| Series | A22RS |
| Mechanical Life | 300,000 Cycles |
| Panel Cutout Dimensions | Circular - 22.30mm Dia |
| Operating Temperature | -20°C ~ 60°C |
| Circuit | DPST (1-NO, 1-NC) |
| Type | Standard |
| Voltage Rating - AC | 120V |
| Approvals | CCC, cULus |
| Part Status | Obsolete |
| Manufacturer | Omron Automation and Safety |
| Illumination | Non-Illuminated |
| Number of Positions | 2 |
| Family | Selector Switches |
| Mounting Type | Panel Mount |
| Current Rating | 10A (AC) |
